COMPACT
Extendable Aluminum Duct
Flexible connection between diffuser and ventilation duct.
Dim: Ø 80-315 mm
About COMPACT
The duct is made from a corrugated, lock-seamed aluminum strip (0.10 mm) and can be easily extended, bent, and compressed again.
Documents
Compact is primarily intended for use as a flexible connection between the diffuser and the ventilation duct, type-approved according to TG certificate no. 0897.
Design
The duct is made from a corrugated, lock-seamed aluminum strip (0.10 mm) and can be easily extended, bent, and compressed again.
Maximum Operating Temperature
+200°C
Standard Length
0.75 m, extendable up to 3 m.
Properties
Fire classification A1
Meets the requirements for airtightness class C/D
Accessories
Insulation sleeve PE30, PE50, A25
Hose clamp SBF
